1、Aluminum alloy diecasting，high shock-resistant,multiple anti-shock design and coating on surface,long term operation in high-frequency vibration and high temperature situation such as roadbed and track.
2、Multiple fix types such as wall mounting and ceiling mounting，beam angle can be adjust up and down by 120°.
3、Reflector are highlight anodic oxidation high imported purity aluminium, high lighting effect.
4、Lamp-house：Using good tempered glass，heat-resistant，shock-resistant，high transmittance.
5、Seal ring：Using heat-resistant silastic.
6、IP Grade:IP65
Specification:
|
Product model |
GNH-FL-MN03-20W-H0I |
GNH-FL-MN03-50W-H0I |
GNH-FL-MN03-70W-H0I |
GNH-FL-MN03-100W-H0I |
GNH-FL-MN03-120W-H0I |
GNH-FL-MN03-150W-H0I |
GNH-FL-MN03-200W-H0I |
|
Input voltage(V) |
85~265V AC |
85~265V AC |
85~265V AC |
85~265V AC |
85~265V AC |
85~265V AC |
85~265V AC |
|
Frequency (Hz) |
50 to 60Hz |
50 to 60Hz |
50 to 60Hz |
50 to 60Hz |
50 to 60Hz |
50 to 60Hz |
50 to 60Hz |
|
Power (W) |
20W |
50W |
70W |
100W |
120W |
150W |
200W |
|
Lumen (lm) |
1900lm-2000lm |
4900lm-5000lm |
6900lm-7000lm |
9500lm-10000lm |
11500lm-12000lm |
13500lm-15000lm |
18000lm-20000lm |
|
LED type |
COB or SMD |
COB or SMD |
COB or SMD |
COB or SMD |
COB or SMD |
COB or SMD |
COB or SMD |
|
Color index (CRI) |
≥75 |
≥75 |
≥75 |
≥75 |
≥75 |
≥75 |
≥75 |
|
Color temperature |
2700-6500k |
2700-6500k |
2700-6500k |
2700-6500k |
2700-6500k |
2700-6500k |
2700-6500k |
|
Efficiency |
≥85% |
≥85% |
≥85% |
≥85% |
≥85% |
≥85% |
≥85% |
|
Life time (Hrs) |
≥50,000H |
≥50,000H |
≥50,000H |
≥50,000H |
≥50,000H |
≥50,000H |
≥50,000H |
|
IP grade |
IP65 |
IP65 |
IP65 |
IP65 |
IP65 |
IP65 |
IP65 |
|
Beam angle |
120° |
120° |
120° |
120° |
120° |
120° |
120° |
|
Work temperature |
-20～+55℃ |
-20～+55℃ |
-20～+55℃ |
-20～+55℃ |
-20～+55℃ |
-20～+55℃ |
-20～+55℃ |
|
Material |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
|
Dimension |
201*166*77mm |
253*194*95mm |
291*250*116mm |
309*250*116mm |
315*310*187mm |
375*310*187mm |
395*340*187mm |
Size:
.jpg)
Key words: led flood light, led project lighting
Greenough Enterprise Co., Ltd produce (AC Driverless dimmable) led T8, IP65 Waterproof led tube light, T5 tube light,Pink meat led tube light, square led panel light, pink led panel light, (AC Driverless dimmable) led spot light, (AC Driverless dimmable) led down light, (AC Driverless dimmable) led flood light, (AC Driverless dimmable) led high bay light, led PAR light, LED rigid strip light, LED aluminum profile linear, 220V LED flexible strip light
Widely used in architectures and large space, such as tunnel, station, seaport, park, sports area and advertising board on the square ,architectural, airport,lawn, marketplace,playground,tennis,court,golf course,basketball court,football court... etc.
|
Part No.
|
Package dimension
|
Net Weight/one lamp
|
Gross Weight
|
|
GNH-FL-MN03-20W-H0I
|
480*370*380mm, 20pcs/carton
|
1.00kg/pc
|
24.5kg
|
|
GNH-FL-MN03-50W-H0I
|
610*530*280mm, 8pcs/carton
|
2.20kg/pc
|
21.70kg
|
|
GNH-FL-MN03-100W-H0I
|
370*350*250mm, 1pcs/carton
|
5.20kg/pc
|
5.77kg
|
|
GNH-FL-MN03-150W-H0I
|
420*380*260mm, 1pcs/carton
|
6.5kg/pc
|
7.34kg
|
|
GNH-FL-MN03-200W-H0I
|
500*440*280mm, 1pcs/carton
|
9.50kg/pc
|
10.00kg
|
