Philips Nichia Chip + Meanwell Driver UFO Led High Bay Light 150lm/w Factory Warehouse LED Industrial Lamp 60w 80w 100w120w 150w 200w 240w

*50000 hours life span.

*It is available in round and square version.

*Available in 60W 80W 100W 120W 150W 200w 240w.

*IP 65 protection level with Meanwell Driver/CE Driver

*With high lighting effect: 150LM/W with Nichia Chips, 135LM/W with Philips Chips

*The input voltage is 90-305VAC

*PF is more than 0.90

*5 years warranty.

*New design, with lighter weight, better heat dissipation, more stable quality, easy to install

*The main accsseries are imported materials, anti-high temperature and anti-corrosion

*The led chips are the imported high brightness chips, with higher lumen output, high thermal conductivity, low luminous decay, pure light color, no ghosting etc

*The lamps are with the angle locking device, to ensure the angle won't be changed for the long-term working in the vibration environment

*Using the latest technology of heat radiation structure, can ensure lamp life

*With Chain, Bracket Pothook etc installation methods.

Download Collection Catalogue Inquire

Specification
Application
Packing Details
Inquire

Greenough Round UFO high quality LED high bay Light, new design for industrial led lighting. Adopting the Nichia3030 or Philips led chip, it is well known Cree, Nichia & Philips are top quality brands in industrial LED market. With longer lifespan, lower maintenance cost, higher efficiency. LED chip could last up to 50000 hours if the heat dissipation is good enough and driving current is correct. It can be up to 150LM/W for Nichia chips, and 135LM/W for Philips Chips

It is available in round and square version, the round one is much popular than square one. With better heat dissipation, more stable quality.

It is with special design heat sink and the top lens for dazzle, the lens is different with others. Also it is with less transportaion cost compare with other styles. As the design of this item UFO LED high bay lamp. light are more fashion and lightness but to maintain unified and perfection of buildings when to be installed, without destroying the luminaire and lights embedded without glare to achieve effect of soft and uniform light.

Name Item			GNH-R-HBL-N-60W	GNH-R-HBL-N-80W GNH-R-HBL-N-100W	GNH-R-HBL-N-120W GNH-R-HBL-N-150W	GNH-R-HBL-N-200W GNH-R-HBL-N-240W
Electrical	Power		60W	80W 100W	120W 150W	200W 240W
	Input Voltage		90-305VAC
	Input Current		0.27A@220VAC	0.36A@220VAC 0.45A@220VAC	0.55A@220VAC 0.68A@220VAC	0.91A@220VAC 1.10A@220VAC
	PF		>0.90@220VAC
	DC output voltage		54V	48V
	DC output current		1.05A	1.5A 1.9A	2.3A 2.9A	3.9A 4.65A
	Dimming (Optinal)		3 in 1 dimming (PWM, 1-10V, Resistor)、Dali
Photometric	CCT		Neutral white（4000K）、Natural white （5000K）、 Cool white （5700K） Warm white（3000K）---can be customized
	Ra >80	Typical Flux	7800 Lm±10%	10400 Lm±10% 13000 Lm±10%	15600 Lm±10% 19500 Lm±10%	26000 Lm±10% 31200 Lm±10%
		Efficiency	130Lm/W±10%
	Ra >70	Typical Flux	8400Lm±10%	11200 Lm±10% 14000 Lm±10%	16800 Lm±10% 21000Lm±10%	28000 Lm±10% 33600Lm±10%
		Efficiency	135-150Lm/W±10%
	LED Brand		Philips 3030
	Beam Angle		60°、90° 120°
Others	Operation Temp.		-40℃ ~ +45℃
	Storage Temp.		-40℃ ~ +85℃
	Life Circle		45℃ 50000Hours
	IP Class		IP65
	IK Class		IK08
	Certificate		UL, CUL, DLC, CE, CB, SAA, Class II Chemical Explosion proof
	Body Color		Black
	Product Size(mm) &Net weight	CE Driver	-	261261125	300300145	330330155
			-	2.9Kg	3.9Kg	6.1Kg
		Meanwell Driver	261261118	261261172	300300190	330330201
			2.3Kg	2.9Kg	3.9Kg	6.3Kg
	Packing Size(mm) &Gross weight	CE Driver	-	325325225	370370240	400400250
			-	3.7Kg	4.9Kg	7.3Kg
		Meanwell Driver	325325225		370370240	400400250
			3.1Kg	3.7Kg	4.9Kg	7.5Kg
	Installation mode		Hook Mount, Pendant Mount, Bracket Mount
